1. Optional: Two testing methods: LCD touch screen and microcomputer;
2. Optional: Multiple testing methods;
3. Optional: Multiple data curves on the screen (2 or more);
4. Microcomputer testing: display 7 dynamic data change curves;
5. Customers can choose research and development specific data processing functions according to their needs;
6. The results are automatically saved in PDF or EXCEL format;
7. Data can be uploaded through communication protocols;
8. During microcomputer testing, sample names and industry national standards can be set
9. Integrated mechanism, real-time measurement in a horizontal stationary state.
The influence of plastic moisture content on products
The moisture in plastic particles, even surface condensed moisture, can cause some problems in the molding and processing of engineering plastics. This water absorption property may have some adverse effects, including problems in processing, poor surface of products, or poor mechanical properties of products, as well as problems affecting the strength, impact resistance, heat resistance, hardness and aging resistance of products.
Moisture content detection of engineering plastics
The "Guanya" brand DF-06 series engineering plastic moisture content detector has functions such as temperature setting and control. It can directly calibrate the testing temperature, view multiple data display curves during the testing process, and set the temperature according to different materials. It is a new generation of plastic rapid moisture determination instrument developed using the internationally recognized drying weight loss principle. It adopts an imported precision weighing system for weighing and sampling, and uses a radiation source to quickly dry the sample. While measuring the weight of the sample, the heating unit and moisture evaporation channel quickly dry the sample. During the drying process, the moisture meter continuously measures and displays the lost moisture content% of the sample in real time. After the drying program is completed, the final measured moisture content value is locked and displayed, and the change in sample mass before and after drying is directly calculated to obtain the moisture content.
The Shenzhen Guanya DF-06 series engineering plastic moisture content detector has obtained multiple patents, including "201820840431.2 New Plastic Moisture Content Determination", "201530405953.1 Moisture Meter", "A New Moisture Meter Heating Treatment System Equipment", "ZL 2005 30101370.6 Moisture Tester", and "Software Copyright of Plastic Moisture Content Measurement Equipment Operation Management System".
| 1 | Weighing range | 0-150.000g (customizable) |
| 2 | Moisture measurement range | 0.01%-100% |
| 3 | Solid content measurement range | 100-0.01% |
| 4 | patent | A moisture detection device for industrial products |
| 5 | Test Mode | Fast (optional/customizable: automatic, timed, standard step, step timed) |
| 6 | parameter settings | Dual Mode |
| 7 | Sample quality | 0.001g-150.000g |
| 8 | Heating temperature range | Ambient temperature -230.0℃ |
| 9 | Temperature resolution | 0.1℃ |
| 10 | patent | A new type of moisture meter heating treatment system equipment |
| 11 | Heating source | Molecular source |
| 12 | Moisture reading accuracy | 0.01%.（100ppm） |
| 13 | show | Color 7-inch LCD touch screen |
| 14 | Calibration Mode | Multi-point calibration |
| 15 | Temperature window | Real-time display of ambient temperature |
| 16 | Device data storage | Store 200 sets of data |
| 17 | Printing function (optional) | Printing in Chinese and English |
| 18 | Sample tray | dedicated |
| 19 | USB communication (optional) | Upper-level data analysis software |
| 20 | parameter | Moisture value (%), solid content (%), current temperature (0.1℃), set temperature (0.1℃), current weight (g), initial weight (g), test time (S), constant weight time (S); date (year, month, day); time (hour, minute, second), weight calibration (g), real dynamic change curve, historical record, contact us |
| 21 | Operation Mode | Full screen touch |
| 22 | voice | Free switch between Chinese and English |
| 23 | Test dynamic curve (optional) | 4 |
| 24 | Working temperature | 5℃－50℃； |
| 25 | Relative humidity | ≤80%RΗ； |
| 26 | power supply | 220V±20V |
| Frequency: 50Hz±1Hz | ||
| 27 | net weight | 4.5Kg |
The "Guanya" brand DF-006 series engineering plastic moisture content detector is commonly used for moisture testing in five types of engineering plastics: polyamide, polycarbonate, polyoxymethylene, ABS resin, and polytetrafluoroethylene. It is also used for moisture testing in powder fillers such as calcium carbonate, refractory materials, talcum powder, aluminum oxide, gypsum, desiccants, ceramic slurries, ceramic powders, and other powders.
